SharpPlant is a .NET wrapper for Intergraph SmartPlant® products, written in C#. It was designed to simplify .NET development, as well as provide additional API functionality as needed. The initial release of this API covers SmartPlant® Review only. However as time, resources and community involvement picks up, the roadmap is planned to expand into further Intergraph products. You can view more about the Intergraph SmartPlant® product line at http://www.intergraph.com

How to Get Started

• Download the latest SharpPlant project zip and build the dll in Visual Studio, or your preferred .NET IDE.
• Add the SharpPlant.dll as a reference to a new or existing .NET solution to make the classes/methods available.
• SharpPlant requires .NET 4.0 or higher as it implements dynamic variables at runtime.

Example Usage

Creating an application reference:

 // Create a new application object
 var sprApp = new SprApplication();

Updating the application text window:

 // Update the application text window
 sprApp.TextWindow_Update("SharpPlant loaded successfully");

Placing a new tag:

 // Create a new tag object
 var newTag = new SprTag();

 // Set the tag properties
 newTag.Text = "High-point vent required as per P&ID";
 newTag.Discipline = "Piping";
 newTag.Creator = "ExampleUser";

 // Place the tag in the active application
 sprApp.Tags_Place(ref newTag);

Placing a new annotation:

 // Create a new annotation object
 var newAnno = new SprAnnotation();

 // Set the annotation properties
 newAnno.Text = "Removable handrail";
 newAnno.DisplayBackground = true;
 newAnno.DisplayLeader = true;
 newAnno.BackgroundColor = System.Drawing.Color.Green;
 newAnno.Persistent = true;

 // Place the annotation in the active application
 sprApp.Annotations_Place(ref newAnno);

Taking a snapshot:

 // Create a new snapshot object
 var newSnap = new SprSnapShot();

 // Set the snapshot properties
 newSnap.AntiAlias = 3;
 newSnap.OutputFormat = SprSnapshotFormat.Png;
 newSnap.Overwrite = true;

 // Take the snapshot
 sprApp.TakeSnapshot(newSnap, "TestImage", @"C:\TestSnapshots\");

Collect object information:

 // Prompt a user to select an object in the active application instance
 var newObjectData = sprApp.GetObjectData("Select an object to view");

DrAPI Object Wrapping:

• DrAPI: SprApplication
• DrAnnotationDbl: SprAnnotation
• DrDisplaySetDbl: NOT WRAPPED
• DrKey: SprLinkage
• DrLongArray: OBSOLETE
• DrMask: NOT WRAPPED
• DrMeasurement: NOT WRAPPED
• DrMeasurementCollection: NOT WRAPPED
• DrObjectDataDbl: SprObject
• DrPointDbl: SprPoint
• DrSnapShot: SprSnapShot
• DrStringArray: OBSOLETE
• DrTransform: NOT WRAPPED
• DrViewDbl: NOT WRAPPED
• DrVolumeAnnotation: NOT WRAPPED
• DrWindow: SprWindow

SmartPlant® Review Development Notes:

SharpPlant does not require the VaxCtrl3.dll to be added as a project reference, however it needs to be registered on any machine it runs on (installing SmartPlant® Review does this automatically).

Additional resources for SmartPlant® Review development can be found in the ..\resdlls\0009 directory inside the local install folder:

• DRAPI_API.cmh
• Drapix_API.chm

If the API module is installed, additional libraries and files will be located in the ..\Api directory inside the local install folder:

• DRAPI.H
• drapi32.dll
• drapi32.lib

Release History

• 4/8/2013 Initial release
• 8/12/2013 Beta 0.4 Release

Contributors

[Parrish Husband] (https://github.com/phusband)

Support/Discussion

[Official support thread at DaveTyner.com] (http://www.davetyner.com/forum/forumdisplay.php?127-Sharp-Plant)

License

SharpPlant is available under the MIT license. See the LICENSE file for more info.
