PyCon Canada 2017

This repository contains the content of my presentation at PyCon Canada 2017.

Aside from the presentation, you will find examples showing how to create and use a Babeltrace 2 component implemented in Python. The component is imaginatively named sink.pycon.StackView (see bt_plugin_pycon.py).

Demos

All the demos presented were based on the tracing of Python's SimpleHTTPRequestHandler serving a local copy of the LTTng home page.

Note that the only LTTng-specific line in httpserver.py is

import lttngust

This sets up all we need to redirect logging statements to LTTng.

See tracing Python applications for more information on the lttngust package.

1) Tracing Python logging statements

Using 1_trace_py_logging.sh, we can setup a tracing session that will trace all events originating from the Python logger for a given PID; the script's first parameter.

In essence, the script sets up the session as such:

# Create a live session named "py_logging"
lttng create py_logging --live

# Enable all Python agent (logger) events
lttng enable-event --python --all

# Only trace userspace events from the PID received as the first argument
lttng track --userspace --pid $1

lttng start

We can then use the lttng view command to see the events as they are produced using Babeltrace.

However, we can also use the sink.pycon.StackView to get a prettier version of the same output.

2) Tracing Python logging statements + syscalls

Where LTTng really shines is when we blend multiple sources of information. In this example, we will setup a new session which traces the same Python logging events. However, we will also trace the syscalls that are invoked by our server.

Again, we can use a new script, 2_trace_py_syscalls.sh to put that session in place. This script executes the following commands.

# Create a live session
lttng create py_syscalls --live

# Enable all Python agent (logger) events
lttng track --userspace --pid $1
lttng enable-event --python --all

# So far, everything is the same as the previous example. However, let's also
# enable the tracing of all syscalls invoked by that same process.
lttng track --kernel --pid $1
lttng enable-event --kernel --syscall --all

lttng start

Using our sink.pycon.StackView component, we then get the following output which shows both the Python logging statements and the syscalls performed on the same timeline.

3) Tracing Python logging statements + syscalls + Python functions

Building on top of the previous example, we can go one level deeper: trace all python functions as they are invoked.

To this end, we need to apply three patches which are under review by the upstream CPython project.

These patches add, amongst others, the following events which can be enabled sing LTTng:

python:function__entry
python:function__return

These new events allow our component to track whenever the Python interpreter enters and exits a Python function.

We can use 3_trace_py_functions.sh to setup a session similar to the previous example. However, we will also enable those two new events.

# Create a live session
lttng create py_functions --live

# Enable Python function tracing
lttng enable-event --userspace python:function__entry
lttng enable-event --userspace python:function__return

# Enable all Python agent (logger) events
lttng track --userspace --pid $1
lttng enable-event --python --all

# Enable all syscalls invoked by python
lttng track --kernel --pid $1
lttng enable-event --kernel --syscall --all

lttng start

Now, let's see how Python logging statements, Python functions, and system calls all interact with each other using our component.

4) Tracing Python logging statements + syscalls + Python functions + CPython functions

Finally, we can go one level deeper. Let's see how we can trace C functions being invoked inside the CPython interpreter.

This requires a bit more work since we must build our own Python interpreter.

Building the interpreter

In order to retrieve the function names from the addresses recorded in the LTTng trace, the binary must contain DWARF debug information and the compiler must instrument the various functions' entry and exit points.

Make sure to build your interpreter with the following CFLAGS:

CFLAGS="-finstrument-functions -g"

While the component will work even if the binary has no DWARF information, it will only be able to display function names which are exported (public symbols). Unknown function names will be shown as ???().

Tracing the software

Our component depends on two events produced by an LTTng-ust helper library:

• lttng_ust_cyg_profile_fast:func_entry
• lttng_ust_cyg_profile_fast:func_exit

LTTng provides the liblttng-ust-cygprofile-fast.so shared object utility in order to trace these events on the functions' entry and exit. For more information, see the LTTng official documentation which has a dedicated section on this mechanism.

Setup a tracing session

The 4_trace_py_native.sh script sets up a session which, on top of those created in the previous examples, enables everything we need to trace native/C functions.

# Create a live session
lttng create py_native --live

# Explicitly create a userspace channel in order to enable context tracing
lttng enable-channel --userspace uchannel

# Trace the vpid (virtual PID) and ip (instruction pointer) contexts
lttng add-context --userspace --channel uchannel --type vpid
lttng add-context --userspace --channel uchannel --type ip

# Enable Python function tracing (Python code)
lttng enable-event --userspace --channel uchannel python:function__entry
lttng enable-event --userspace --channel uchannel python:function__return

# Enable Python interpreter function tracing (C code)
lttng enable-event --userspace --channel uchannel lttng_ust_cyg_profile_fast:func_entry
lttng enable-event --userspace --channel uchannel lttng_ust_cyg_profile_fast:func_exit

# Enable statedump events which allow the reader to map back instruction
# pointer addresses to the various libraries and binaries
lttng enable-event --userspace --channel uchannel 'lttng_ust_lib:*'
lttng enable-event --userspace --channel uchannel 'lttng_ust_statedump:*'

# Enable all Python agent (logger) events
lttng track --userspace --pid $1
lttng enable-event --python --all

# Enable all syscalls invoked by python
lttng track --kernel --pid $1
lttng enable-event --kernel --syscall --all

lttng start

Launching the web server with LD_PRELOAD

LD_PRELOAD=/usr/lib/liblttng-ust-cyg-profile-fast.so python httpserver.py

Tying it all together!

As you can see in the demo below, we now see all the syscalls and C functions that go into the execution of our Python web server!

Of course, this is way too much information if you are not debugging a very precise problem within CPython. However, it shows how easily LTTng can be used to collect pretty much any information you need to understand what is going on at any layer of your system.

You may notice that all C functions initially show up as ???(). This is because our viewer is hooking up at a random point in the trace and can't translate the instruction pointer into function names.

The lttng regenerate statedump command is used in another terminal to force LTTng to emit the events which will provide Babeltrace with the information it needs to map all instruction addresses to human-readable function names.

Note that this demo seems to be giving Asciinema a run for its money, click here if the preview does not show up! :-)
