A tool for sculpting in Blender with a focus on terrain. Blender's default sculpting tools are great for character models, but are difficult to use when you're trying to sculpt terrain. This tool suite provides options for leveling ground, creating ramps and constraining your changes to be perpendicular to the ground. It's meant to allow you to quickly block in a terrain in the early stages of your project.
These tools can be accessed through the Kitfox - Terrain panel on the right of the 3D Viewport. You can also access them from the uv unwrap menu (press U while in edit mode).
Start by creating the mesh for your terrain (for example, a grid mesh that is 100 x 100 units). Make sure you are in Object mode. Select the object and click the Terrain Brush for Meshes button in the Terrain Sculpt Mesh Brush panel. The tool will start and a pink circle will appear under your mouse cursor. Click and drag on the mesh to sculpt your terrain.
The tool will also work if you have multiple mesh objects selected. This can be used to create seamless transitions between two meshes.
You might find that this tool is a bit laggy on larger meshes. The way to deal with that is to subdivide your mesh into smaller pieces. This way the brush only has to recalculate the mesh that is actually under the brush. If you need to draw over the seam between two meshes, just make sure that all meshes you want to draw on are selected before you start the tool.
Use sculpting tools to move vertices to create landscapes.
Start the UV Brush tool. Pressing Enter will commit your changes, ESC will cancel your changes. You can press Ctrl-Z to undo a stroke or Shift-Z to redo a stroke.
You will be unable to use the menu panel while the tool is active (this is a current limitation of Blender) - however, there are a number of keyboard shortcuts you can use to adjust to tool while it is running.
Radius of brush stroke. You can press the [ and ] keys to change the radius of the brush.
Used to adjust the hardness of the brush. The space between the outer and inner radius provides a falloff region for your stroke. You can press the Shift-[ and Shift-] keys to change the inner radius of the brush.
Multiplier for the strength of your brush stroke.
If checked, the pressure you apply with your stylus will multiply the strength of your brush.
By default, the brushes use the world origin as the reference point for all measurements. However, if you would like to choose a different world center, you can specify it here. This is mostly useful for Sphere mode where you would like the center of your world to be in the middle of the mesh you are sculpting.
Select the behavior of the brush you are drawing with. You can press and hold Shift at any time to temporarily switch into Smooth mode.
Shortcut D.
Draws terrain under the brush up to the current Draw Height. This can be used to create a terraced landscape. Press and hold Ctrl to temporarily change the draw brush into the height picker. This can be used to quickly set a new height for your terraces. The Up Arrow and Down Arrow keys can be used to add and subtract a quarter of the brush radius to the terrain height.
Shortcut L.
Same as Draw, but uses the height of the terrain where you start your brush stroke rather than referring to the Draw Height.
Shortcut A.
Brush strokes will build up on top of existing geometry. Press and hold Ctrl to temporarily switch to Subtract mode.
Shortcut S.
Brush strokes will dig trenches in existing geometry. Press and hold Ctrl to temporarily switch to Add mode.
Shortcut P.
Calculates the average slope under the cursor and uses that sloping plane to even out the vertices under it.
Shortcut M.
Calculates the average height under the cursor and then uses that height to draw a level surface.
Shortcut R.
Click and drag from one location to another to create a ramp between those locations.
Allows you to switch between Flat and Sphere mode. Flat mode presumes a flat work where down is always in the negative Z direction. Sphere mode is used for drawing on spheres for planet like terrains. In Sphere mode, is always the Terrain Origin if you have set is, or the world origin if you have not.
In Draw mode, specifies the height above the world origin terrain will be drawn at in Draw mode.
Used to pick the terrain height be sampling your scene. Click the button to start the tool and then click a mesh in the viewport to set the new drawing height.
In Add and Subtract modes, a multiplier that modifies how much is added to subtracted when stroking the brush.
In Ramp mode, indicates how wide the ramp you are drawing will be.
In Ramp mode, indicates how much rounding will be applied to the edges of your ramp.
To build, execute the makeDeploy.py script in the root of the project. It will create a directory called deploy that contains a zip file containing the addon.
To install, start Blender and select Edit > Preferences from the menubar. Select the Add-ons tab and then press the Install button. Browse to the .zip file that you built and select it. Finally, tick the checkbox next to Add Mesh: Terrain Sculpting Tools.
This addon is available at the Blender market: https://github.com/blackears/blenderTerrainSculpt
A video giving a quick tour of the addon is available here:
